    9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part

    Ask Lasest Price
    Brand Name : Techcore
    Model Number : Packer Redress Kit
    Certification : ISO, BV, SGS
    Price : Negotiable
    Supply Ability : 50sets/month
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part

    9 5/8" Full Bore Retrievable Packer Redress Kit / RTTS Packer Part List
    The Full Bore Retrievable Packer is the mechanical setting double grip packer. The retrievable packer is used in drill stem testing service, well completion operation and TCP operation. The retrievable packer is composed of a Auto J slot mechanism,mechanical slips, Packing elements and hydraulic slips, also equipped with the drag-block.
    Part list of Retrievable Packer

    Part List
    NoPart NumberDescriptionaty
    1102146667-01Hydraulic Holddown body1
    2102146667-02.00Hydraulic holddown slip12
    3102146667-03Holding Strap4
    4102146667-04Spring24
    5102146667-05Top Shoe1
    6Table 1Packer element2
    7102146667-07Spacer ring1
    8102146667-08Lower shoe1
    9102146667-09Mechanical slip body1
    10102146667-10Volume tube1
    11102146667-11Upper mandrel1
    12102146667-12Slip stop pin8
    13102146667-13.00Mechanical slip8
    14102146667-14Split Ring collar1
    15102146667-15Screw4
    16102146667-16Lower mandrel1
    17102146667-17.00Dragblock sleeve1
    18102146667-18.00Drag block8
    19102146667-19Dragblock spring32
    20102146667-20Keeper8
    21102146667-21Lower adapter1
    22102146667-22Slip Insert Bolt24
    232-3490-ring2
    242-4300-ring1
    252-4320-ring1
    262-4260-ring1
    272-2470-ring1
    282-2500-ring1
    282-3320-ring12

    * The parts of retrievable packer are interchangeable with RTTS Packer in Halliburton Type

    9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part 9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part 9 5/8" Full Bore Retrievable Packer Redress Kit RTTS Part


    Advantage of ZZ TOP OIL TOOLS

    ZZ TOP Oil Tools expertise in manufacture of the Drill Stem Testing Tools for more than Ten years, the professional Reserch and Development (R&D) department improves the advanced technology in design of the Drill stem testing tools for well testing service.

    ZZ TOP designs and chooses the raw material of DST tools according to the customers' oil well condition, and make all our effort to supply the cost effective well testing tools to satisfy the customer, and improve the test tools to meet the industry’s demand for ultra-high pressure and temperature downhole operation.

    * Drill stem testing tools are available for cased hole, open hole and slim hole including:

    * Full bore retrievable packer, full bore retrievable circulating valve, full bore retrievable safety joint,
    * Downhole tester valve, select tester valve, LPR- N Valve,
    * OMNI valve, multi-cycle circulating valve, hydraulic jar, vertical shock absorber, radial shock absorber, RD safety circulating valve,
    * High pressure retrievable packer with bypass, CHAMP packer, IPO valve, tubing string test valve, sleeve type drain valve, rupture disk sampler, super safety valve with control panel, BOP safety valve for downhole operation and so on.

    Welcome to contact us for more information!
