Drill Stem Testing Tool String Vertical Shock Absorber & Radial Shock Absorber

The shock absorber is a part of the DST tool string used for oil and gas well testing opeation. There are two types of shock absorber: Radial shock absorber and Vertical shock absorber.

The radial shock absorber protect pressure-measuring equipment or sensitive components in the workstring for shock loads transmitted through the workstring by firing of TCP guns. It can also help straighten the workstring. This radial shock absorber is mainly composed by radial shock absorption component and axial slide component. The radial shock absorption component include block retainer , housing retainer,block , block spring retention and spring. The axial slide component include housing retainer, lower adapter, mandrel , shear pin , lower bearing thrust and ring shear

The vertical shock from axial slide can be transferred to the vertical shock absorber, a part of shock will be absorbed by axial slide movement and the shear pin effect, so that the condition of radial shock absorber component and inner-wall tubing are relative stable.

Technical Parameter of Raidal shock absorber

Techcore oil tools is certified by ISO, all the manufacture is strictly conformed with ISO system including Quality Control Management, Environmental Management and Occupational Health & Safety Management. For each downhole tools and each parts, we make the trace-ability from the raw material till the products. And any TPI inspection are available with us from SGS/BV/ TUV /DNV etc..

* Drill stem testing tools for cased hole, open hole and slim hole manufactured by Techcore

Full bore retrievable packer, full bore retrievable circulating valve, full bore retrievable safety joint, downhole tester valve, select tester valve, LPR- N Valve, omni valve, multi-cycle circulating valve, hydraulic jar, vertical shock absorber, radial shock absorber, RD safety circulating valve, high pressure retrievable packer with bypass, CHAMP packer, IPO valve, tubing string test valve, sleeve type drain valve, rupture disk sampler, super safety valve with control panel, BOP safety valve for downhole operation and so on.

Welcome to contact us for more information about our tools and service!!

ZZ Top Oil Tools Co.,Ltd as head office registered in Xi’an City in 2010, and in 2016, ZZ TOP OIL TOOLS enlarged the downhole oil tools factory under the Brand - TECHCORE in Baoji, which engages in designing and manufacturing the downhole oil tools including DST tools, Coiled tubing tools etc.

As one group, ZZ TOP provides the clients highly efficient & expertise service as well as more comprehensive products to meet the customers' requirements during the work, and insists on "Traceability, Serialization" for each tools and related parts

Equipments List

Techcore specialized in design, manufacture and sales of the oil well downhole tools as below:

* Drill stem testing tools for cased hole,  open hole and slim hole:

Retrievable packer, circulating valve,safety joint, downhole tester valve,LPR- N Valve, multi-cycle circulating valve, hydraulic jar, shock absorber, RD safety circulating valve,CHAMP packer, IPO valve, tubing string test valve, drain valve,RD sampler, super safety valve etc.

* Coiled Tubing Tools: Double slip connector, roll on connector, roll on x thread connector, double flapper check valve, motor head, dual function circulating valve, hydraulic jar, fishing tools etc.

* Perforating tools: Various perforator & perforating gun system, Shaped Charge Body

 *Oil well completion tools include: Subsurface safety valve, wireline retrievable subsurface safety valve, single string production packer, dual strings production packer, ESP packer, mechanical set packer, permanent packer, compensation device, bridge plug, sliding sleeve, nipples etc.
